Power：150W
Series：CC LED Driver
Application：Street and area lights
Certificate：UL/cUL, ENEC05, RCM, CCC, CB, Class P, NOM, IP67
Warranty：5 years
CC LED Driver
Efficiency up to 93%
Isolated dimming: 1-10V, PWM, Resistor, Timing
IP67
Protections: SCP/OTP/OVP/OPP
Class P
TYPE HL, suitable for hazardous locations
Surge protection: CM: 10kV, DM: 6kV
Warranty: 5 years
| Reted input voltage | 100~277ac |
| Input Frequency Range | 50/60Hz |
| Max. Pout | 150W |
| Dimension | 201*71*39.6（mm） |
| Model | AC Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（A） | THD(Typ.) | PF(Typ.) | Eff.(Typ.) | Max.Tc |
| SS-150VA-56* | 90-305 | 150 | 22-56 |
36-56 |
2.1-4.2 | 8% | 0.98 | 93% | 90℃ |
| Carton dimension | L×W×H =495×385×162(mm) |
| QTY | 14 PCS |
| Net weight/PC | 0.96kg |
| Gross weight/Carton | 14.4kg |
