Power：165W
Series：DALI-2 Version
Application：Street light, Tunnel light, Industrial and sports light
Certificate：ENEC, CE, UKCA, EAC, DALI-2
Warranty：8 years
DALI-2 Version
Efficiency up to 94%
Adjusted via NFC
DALI-2 certifed, Part 251, 252, 253
Standby power consumption≤0.5W
Surge Protection: CM: 10kV, DM: 6kV
Timing/ELA/CLO
Protections: SCP/OTP/OVP/OPP
Suitable for Class I /II luminaires
IP20
Installation dimensions conform to Zhaga standards
Warranty: 8 years
| Reted input voltage | 220~240Vac |
| Input Frequency Range | 50/60Hz |
| Max. Pout | 165W |
| Dimension | 171*101*35（mm） |
| Model | Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（A） | THD(Typ.) | PF(Typ.) | Eff.(Typ.) | Max.Tc |
| SS-165PA-157D |
198-264 |
165 | 54-157 |
110-157 |
0.2-1.5 | 6% | 0.98 | 93.5% | 90℃ |
| SS-165PA-236D |
198-264 |
165 | 79-236 |
157-236 |
0.2-1.05 | 6% | 0.98 | 94% | 90℃ |
| SS-165PA-367D |
198-264 |
165 | 118-367 |
236-367 |
0.2-0.7 | 6% | 0.98 | 94% | 90℃ |
| Carton dimension | L×W×H =445×225×145 (mm) |
| QTY | 12 PCS |
| Net weight/PC | 0.933kg |
| Gross weight/Carton | 12.2kg |
