Power：40W
Series：CC LED Driver
Application：Street and area light
Certificate：CCC, IP67
Warranty：5 years
CC LED Driver
Efficiency up to 89%
Isolated dimming: 1-10V, PWM, Resistor, Timing
IP67
Protections: SCP/OVP
TYPE HL, suitable for hazardous locations
Surge protection: CM: 10kV, DM: 6kV
Warranty: 5 years
| Reted input voltage | 100~277ac |
| Input Frequency Range | 50/60Hz |
| Max. Pout | 40W |
| Dimension | 132*50*31（mm） |
| Model | AC Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（A） | THD(Typ.) | PF(Typ.) | Eff.(Typ.) | Max.Tc |
| SS-40VA-T | 90-305 | 40 | 28-50V |
36-50 |
0.64-1.1 | 12% | 0.97 | 89% | 90℃ |
| Carton dimension | L×W×H =495×385×162 (mm) |
| QTY | 42 PCS |
| Net weight/PC | 0.415kg |
| Gross weight/Carton | 18.9kg |
