Power：150W
Series：CC LED Driver
Application：High bay light, High pole light
Certificate：UL/cUL, TUV, CE, DALI-2
Warranty：5 years
CC LED Driver
Efficiency up to 95%
Isolated dimming: DALI-2, 0-10V, PWM, Resistor
Optional aux: 12V/0.2A
IP65
Protections: SCP/OTP/OVP
Surge protection: CM: 6kV, DM: 6kV
Warranty: 5 years
| Reted input voltage | 120-277Vac |
| Input Frequency Range | 50/60HZ |
| Max. Pout | 150W |
| Dimension | φ128*62.5（mm） |
| Model | AC Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（A） | THD(Typ.) | PF(Typ.) | Eff.(Typ.) | Max.Tc |
| SS-150CNL-E260* | 90-305 | 150 | 180-260 |
200-260 |
0.52-0.75 | 8% | 0.97 | 95% | 90℃ |
| Carton dimension | L×W×H =495×385×162 (mm) |
| QTY | 9 PCS |
| Net weight/PC | 0.735kg |
| Gross weight/Carton | 7.81kg |
