SS-1200VP-GXX

SS-1200VP-GXX

Product Features

Power:1200W

Series:CC LED Driver

Application:Stadium light, High pole light, Horticulture light, Fish light

Certificate:ENEC, UKCA, CE, CB, DALI-2

Warranty:5 years

Product Description

CC LED Driver

Consult lmmediately
Specifications
Features
Parameters
Reference
Packing

Efficiency up to 95.5%

Dimming: DALI-2, 0-10V, PWM, Resistor, Timing

Dim-to-Off

Surge Protection: CM: 10kV, DM: 6kV

AUX Power: 12V/0.3A

Constant Lumen, Life Warning

External NTC to Protect LED Module

Standby Power<0.5W

IP67

Communication Function With PC

Type HL, suitable for hazardous locations

Protections: SCP/OTP/OVP

Warranty: 5 years

 Warranty: 8 years(Optional)

Reted input voltage 200~277Vac
Input Frequency Range 50/60HZ
Max. Pout 1200W
Dimension 310*144*49.5(mm)
Model AC Input Range(Vac) Vout Range(Vdc) Full Power Vout Range(Vdc) Iout(A) THD(Typ.) PF(Typ.) Eff.(Typ.) Max.Tc
SS-1200VP-GXX 176-305 100-200 150-200 1.05-8 5% 0.95 95.5% 90℃
Outside carton dimension L×W×H =495×385×162 (mm)
Number of packages per Carton 4 PCS
Net weight/PC 4.2kg
Gross weight/Carton 18.3kg
