SS-200GA-EXXX*

SS-200GA-EXXX*

Product Features

Power：200W

Series：CC LED Driver

Application：High Pole light, High bay light, Stadium light, Horticulture light, Fish light, Street light, Tunnel light, Stage light

Certificate：ENEC, EAC, CCC, CE, UKCA

Warranty：5 years

Product Description

CC LED Driver

Consult lmmediately
Specifications
Features
Reference
Parameters
Packing

Efficiency up to 94.5%

Output current adjustment method: Dimmer line programming

Isolated dimming: 0-10V, PWM, Resistor

TIM，ELA，CLO

Suitable for Class I /II lamps

Protections: SCP/OTP/OVP/OPP

Surge protection: CM: 10kV, DM: 6kV

IP66/IP67

Warranty: 5 years

    ModelAC Input Range（Vac）Max. Pout（W）Vout Range（Vdc）Full Power Vout Range（Vdc）Iout（A）THD(Typ.)PF(Typ.)Eff.(Typ.)Max.Tc
    SS-200GA-E62*100-30520030-62

    40-62

    		0.7-5.08%0.9892%90℃
    SS-200GA-E286*100-305200143-286

    190-286

    		0.1-1.058%0.9894%90℃
    SS-200GA-E378*100-305200189-378

    286-378

    		0.1-0.78%0.9894%90℃
    Reted Input Voltage100~305Vac
    Input Frequency Range50/60Hz
    Max. Pout200W
    Dimension165*66*37（mm）
    Carton DimensionL×W×H =495×385×162 (mm)
    QTY14 PCS
    Net Weight/PC0.74kg
    Gross Weight/Carton11.9kg
