SS-800VP-EXXBH*

SS-800VP-EXXBH*

Product Features

Power:800W

Series:CC LED Driver

Application:Horticulture light

Certificate:UL/cUL, ENEC, CB, CE

Warranty:5 years

Product Description

CC LED Driver

Consult lmmediately
Specifications
Reference
Packing
Parameters
Features
Model AC Input Range(Vac) Max. Pout(W) Vout Range(Vdc) Full Power Vout Range(Vdc) Iout (A) THD(Typ.) PF(Typ.) Eff.(Typ.) Max.Tc
SS-800VP-E56BH* 90-305 800 28-56 48-56 1.75-16.7 10% 0.95 95% 90℃
Carton dimension L×W×H =577×385×162 (mm)
QTY 5PCS
Net weight/PC 2.95kg
Gross weight/Carton 16.2kg



Reted input voltage

120-277Vac

Input Frequency Range 50/60Hz
Max. Pout 800W
Dimension 390*89.5*44.5(mm)

Efficiency up to 95.5%
Dimming: 0-10V, PWM, Resistor, Timing
Dim-to-Off
Surge Protection: CM: 10kV, DM: 6kV
AUX Power:12V/0.2A
Constant Lumen, Life Warning
Standby Power<0.5W
Communication Function With PC
Type HL, suitable for hazardous locations
Protections: SCP/OTP/OVP
Warranty: 5 years
